Fantech RAPID Response 200/250HP Ducted Ceiling Exhaust Fan IPX4 - Timer or No Timer

The Fantech Rapid Response ducted range brings quiet, powerful extraction to bathrooms, ensuites and toilets — available as the Rapid Response 200 or the high-performance 250HP, each with or without a run-on timer. An aerodynamic, fully optimised header-box design minimises airflow resistance, and high-strength swing clips with a removable spigot make retrofitting into a standard round cut-out easy.

Features

• Two sizes — Rapid Response 200 (216m³/hr) or high-performance 250HP (349m³/hr)
• Quiet operation — 29 dB(A) (200) / 37 dB(A) (250HP) @ 3m
• Optional 3–15 minute adjustable run-on timer
• Retrofits into a standard 8" (200) or 10" (250HP) round cut-out
• Low-resistance non-return backdraft damper
• Sealed-for-life ball bearings
• High-strength swing clips & removable spigot for easy install
• IPX4 rated
• Round or square grille options (sold separately)
• 5 Year Replacement Warranty

Specifications

	Rapid Response 200	Rapid Response 250HP
Air Flow	216m³/hr (60 L/s)	349m³/hr (97 L/s)
Fan Speed	950 rpm	950 rpm
Noise @ 3m	29 dB(A)	37 dB(A)
Power	30W	60W
Voltage	230–240V	230–240V
IP Rating	IPX4	IPX4
Cut-out	Ø250mm (8")	Ø290mm (10")
Height	195mm	197mm
Warranty	5 Year	5 Year

Model Codes:

	No Timer	With Timer
Rapid Response 200	RESPF8	RESPF8-T
Rapid Response 250HP	RESPF150	RESPF150T

Timer models (RESPF8-T / RESPF150T) include a 4-pin plug & lead to suit HPM 33 or Clipsal 413/4P bases. Grilles (round or square, with or without LED) sold separately.
